Product Description

This high-performance Industrial UV Dryer is engineered for fast, instantaneous drying of silkscreen printed logos and graphics on bottles. Equipped with imported high-concentrator reflective lampshades, adjustable UV lamps, and a stepless speed-regulated conveyor belt, it delivers consistent curing performance with built-in safety protection.

Key Features & Advantages:

• High-Efficiency Curing: Concentrator design with imported reflective lampshades enables instantaneous, high-speed drying.

• Adjustable Lamp Height: Each UV lamp height can be adjusted up and down to match diverse product requirements.

• Stepless Conveyor Regulation: Features stepless speed regulation for smooth, stable conveying, supported by an anti-deviation drive net belt device.

• Safety & Ventilation: Built-in specially designed internal ventilation system in the light box along with lamp abnormal protection device for maximum operational safety.

•


Technical Specifications Highlights:

• Model No.: SZBD-33-FLK

• Control Method: Motor

• Light Tube Power: 3 kW * 2 pcs (6 kW Total / 6000 W)

• Convey Motor: 50W, 1:15

• Convey Belt Width: 500 mm

• Inlet Height: 10400 mm (adjustable)

• Material Inlet / Outlet Length: 600 mm / 600 mm

• UV Interval Distance: 1300 mm

• Machine Dimension: 2500 750 1600 mm
