Product Description

The Single-Station Edge Cutting Machine is specifically designed for high-efficiency, clean edge cutting and trimming of cookware bodies, pots, pans, and metal containers. Built with a robust hydraulic system, programmable PLC, and user-friendly HMI text interface, this compact single-station unit delivers smooth cutting profiles, uniform workpiece dimensions, and flexible height adjustments via a screw rod positioning mechanism.

Key Technical Features & Advantages

• Hydraulic System Power: Driven by a high-pressure hydraulic circuit, ensuring strong clamping force and clean, burr-free edge shearing.

• Programmable PLC & HMI Control: Features an industrial PLC paired with an intuitive text control panel for simplified operational management and process parameter setup.

• Screw Rod Height & Size Adjustment: Equipped with an adjustable screw rod design to quickly modify working height and workpiece sizing during product changeovers.

• Variable-Frequency Speed Control: Allows smooth rotation and feed speed tuning to suit various metal types and sheet gauges.

• Compact Single-Station Footprint: Heavy-duty vertical frame structure (1300 1000 1900 mm) saves floor space while maintaining high structural rigidity.

•


Industrial Applications

• Metal cookware, pot, pan, and kettle rim cutting and edge trimming

• Stainless steel, aluminum, and brass vessel edge shearing

• Round and cylindrical metal shell edge finishing for hardware production

•


Frequently Asked Questions (FAQ)

Q1: How is the workpiece height adjusted on this machine?

A: It features a screw rod adjustment mechanism that allows quick, manual fine-tuning for different product heights and sizes.

Q2: What is the processing capacity regarding workpiece dimensions?

A: It accommodates workpiece diameters up to 400 mm, heights up to 150 mm, and sheet thicknesses from 0.8 mm to 5 mm.
