Product Description

The Water Leakage Testing Machine is a reliable industrial quality-control system designed specifically for inspecting water tightness and leakage after the welding of bottom discs on vacuum bottles. Built with a transparent tempered glass water tank, rust-proof aluminum clamping structures, and ergonomic rotary controls, this machine provides clear visual inspection and high throughput for metal container manufacturing lines.

Key Machinery Features:

• Tempered Glass Water Tank: Constructed with high-durability tempered glass for clear observation during bubble and immersion leak testing.

• Integrated Working Lamp: Equipped with a dedicated inspection lamp to ensure excellent visibility inside the testing chamber.

• Lightweight Rust-Proof Aluminum Clamps: Utilizes aluminum alloy clamping structures to prevent rust, reduce fixture weight, and extend machine lifespan.

• Simple Rotary Controls: Designed with intuitive rotary switches and physical buttons for effortless daily operation.

• High-Throughput Pneumatic Testing: Features a fully pneumatic drive operating at 0.50.8 MPa, capable of high-volume shift inspection.

Industrial Applications:

• Water tightness and bubble leak testing after bottom disc welding on stainless steel vacuum flasks

• Pressure immersion testing for cylindrical metal bottles and containers

Technical Sections:

• Pneumatic Control & Chamber Design: Operates on pneumatic control within a 0.50.8 MPa pressure range. Incorporates an illuminated tempered glass immersion tank and corrosion-resistant aluminum clamping fixtures for optimal optical clarity during testing.

• Dimensions & Capacity: Built with a compact machine footprint (1185 x 950 x 920 mm) and lightweight frame (200 kg) running at 0.2 kW power. Accommodates bottle diameters of 30120 mm, lengths of 80350 mm, and wall thicknesses of 0.30.8 mm, delivering a capacity of 8,00010,000 pcs per 10-hour shift.

•


Frequently Asked Questions (FAQ):

• Q: What is the main application of this water leakage testing machine?

• A: It is specifically designed for leakage testing after the welding of bottom discs on vacuum bottles.

• Q: What materials are used for the clamping mechanism?

• A: The clamping structure uses aluminum material to prevent rusting and reduce weight.
