Product Description

The 2 Station Top and Bottom Shaping Machine is a high-precision metal forming solution engineered for the shaping of shoulders, beadings, and bottoms of stainless steel bottles and flasks. Utilizing advanced hydraulic extrusion technology combined with a double-position design and CNC servo motor control, this machine delivers outstanding efficiency, quick fine-tuning capabilities, and consistent forming quality for container manufacturing lines.

Key Machinery Features:

• Hydraulic Extrusion Technology: Advanced hydraulic technology enables high-performance forming, shoulder shaping, beading, and bottom shaping.

• Double-Position Workstations: Two-station configuration allows shoulder shaping to be completed in just two quick steps, significantly boosting throughput and productivity.

• Micro-Adjustment Mechanism: Features fine upward and downward adjustment for both stations to ensure convenient setup and high operational flexibility.

Industrial Applications:

• Shoulder shaping, bottom shaping, and beading for stainless steel vacuum bottles and flasks

• Metal pipe and tubular container precision end forming

Technical Sections:

• CNC Servo Control System: Powered by a CNC Servo Motor system (Xin Je) that provides exact motion control, high repeat stability, and smooth operation.

• Safety & Operational Features: Equipped with dynamic pneumatic pressure limits and robust frame support for low maintenance and safe continuous running.

•


Frequently Asked Questions (FAQ):

• Q: What is the production capacity of this shaping machine? A: It reaches a production output of 8,00010,000 pcs per 10-hour shift.

• Q: What wall thickness can this machine shape? A: It is designed for processing pipe thicknesses between 0.3 mm and 0.8 mm.
