Product Description

The Ultrasonic Washing and Dry Machine is an advanced, high-efficiency industrial cleaning solution designed specifically for washing flasks before welding discs. By integrating ultrasonic cleaning with mechanical swing actions, mechanical arm transferring, and automatic drying tunnels, this automated system thoroughly removes oil dirt and contaminants while maximizing energy conservation and production throughput.

Key Machinery Features:

• Ultrasonic Washing & Mechanical Swing: Combines ultrasonic cleaning power with mechanical swing motion to effectively eliminate residual oil and dirt from parts.

• Advanced Arm Transferring System: Replaces traditional chain transfer methods with an automated mechanical arm system featuring left-right slant functions for smooth processing.

• Automated Cleaning & Drying Cycle: Once the washing basket is fed, the system automatically moves it to the cleaning position and executes programmed washing and drying steps.

• Energy-Saving Water Recycling: Recycles all water across each cleaning tank to conserve resources, while utilizing waste heat from heaters to keep immersion tanks warm.

• Dry Tunnel Air Isolation: Equipped with automatic doors at both ends of the dry tunnel to minimize cool and hot air mixing, significantly saving electric power.

Industrial Applications:

• Ultrasonic washing and drying of metal flasks prior to welding operations

• High-efficiency cleaning and drying for industrial metal components and containers

Technical Sections:

• CNC & Ultrasonic Control System: Driven by advanced CNC and ultrasonic control methods to deliver high cleaning efficiency, low fault rates, and convenient maintenance.

• Heavy-Duty Construction & Performance: Built with large-scale structural dimensions (9300 x 1690 x 2320 mm), a net weight of 3,400 kg, and an integrated 25 kW heating furnace.

•


Frequently Asked Questions (FAQ):

• Q: What is the production capacity of this washing and dry machine?

• A: It delivers a high-volume capacity of 15,00030,000 pieces per 10-hour shift.

• Q: How does the system conserve energy during operation?

• A: It recycles tank water, utilizes waste heat for immersion tanks, and features automatic doors on the drying tunnel to prevent thermal loss.
