Product Details:
- Grade Standard Industrial Grade
- Form Heavy-Duty Cabinet Frame / Dual Station
- Power 12050 Watt (w)
- Application Surface Stainless Steel / Aluminum / Metal Outer Edges & Bottom R-Angles
- Usage & Applications Bottom R-angle polishing and top edge finishing for pots, pans, and metal containers
- Polish Type Other
- Finish Type Glossy, Semi-Gloss, Matte
Cookware External R bottom and edge polishing machine Price And Quantity
- 15000 USD ($)/Set
- 1 Set
Cookware External R bottom and edge polishing machine Product Specifications
- Opaque
- 0.6 mpa
- Blue
- 2200 Kilograms (kg)
- 2 Pcs/min
- 12050 Watt (w)
- Heavy-Duty Cabinet Frame / Dual Station
- Industrial Grade
- 150 Millimeter (mm)
- 1 Year
- Stainless Steel / Aluminum / Metal Outer Edges & Bottom R-Angles
- 380 Volt (v)
- N/A
- Bottom R-angle polishing and top edge finishing for pots, pans, and metal containers
- Yes
- External R Bottom and Edge Polishing Machine
- Other
- Industrial
- Semi-Automatic
- R-angle Polishing Wheel, Edge Polishing Wheel, Workpiece Fixture
- Heavy Duty Steel Frame / Alloy Structural Components
- Glossy, Semi-Gloss, Matte
- Hydraulic
- Auto Lubrication
- 4-6 min per Piece (Depending on Complexity)
- Up to 5 mm
- 60 mm
- Touch Screen HMI
- Manual & Automatic Compatible
- <75 dB (Operational)
- G-code, Customizable Programs
- High Precision, CNC Controlled
- 0.05 mm
- Integrated Water Cooling
- On-site Installation & Training Available
- Available
- USB / LAN Supported
- Protective Enclosures, Overload Protection
Cookware External R bottom and edge polishing machine Trade Information
- Telegraphic Transfer (T/T)
- 1-5 Set Per Month
- 20 Days
- Contact us for information regarding our sample policy
- Standard export packaging with wooden case / iron frame packaging.
- Asia, Middle East, Africa
- All India
- Available upon request
Product Description
The External R Bottom and Edge Polishing Machine is a specialized surface finishing equipment designed for precision polishing of bottom R-angles and top edges of cylindrical metal containers. Equipped with dual high-power polishing heads (7.5 kW for R-angle and 4 kW for edge) operating at a spindle speed of 2900 rpm, it efficiently processes workpieces up to 350 mm in diameter and 250 mm in height, delivering smooth and uniform surface finishes for industrial mass production.
Key Features & Highlights:
-
Dual-Head Polishing System: Features dedicated motors for R-bottom angle polishing (7.5 kW) and edge polishing (4 kW).
-
High Spindle Speed: Operates at a polishing wheel spindle speed of 2900 rpm for optimal surface shine and defect removal.
-
Controlled Workpiece Rotation: Driven by a 0.55 kW workpiece motor running at a steady 56 rpm for consistent circumferential coverage.
-
Large Capacity Handling: Accommodates maximum workpiece dimensions up to 350 mm in diameter and 250 mm in height.
Industrial Applications: Widely applied for external bottom corner (R-angle) and top edge polishing of stainless steel cookware, pots, stockpots, pans, kettles, and round metal hardware containers.
Frequently Asked Questions (FAQ):
-
Q: What is the maximum workpiece size this polishing machine can handle?
-
A: It supports maximum workpiece dimensions of 350 mm in diameter by 250 mm in height.
-
Q: What are the power specifications for the polishing motors?
-
A: The R-angle polishing motor is 7.5 kW and the edge polishing motor is 4 kW.
