Product Description

The Single-Side Pinching Machine (Single-Side Hole Punching Machine) is specifically designed for precise, efficient single-side hole punching, piercing, and pinching operations on metal cookware bodies, pots, pans, and cylindrical metal shells. Driven by a compact and powerful hydraulic system, this machine delivers clean, burr-free hole processing for handles, rivets, and side fittings. Its space-saving footprint (600 600 1600 mm) and ergonomic foot-pedal switch make it an highly versatile unit for cookware manufacturing lines.

Key Technical Features & Advantages

• Hydraulic System Powered: Features a heavy-duty hydraulic drive unit that provides smooth punching force and clean edge punching without deformation.

• Compact Footprint & Rigid Frame: Designed with a slim vertical cabinet structure (600 600 1600 mm) weighing approximately 300 kg, optimizing floor space while ensuring operational stability.

• Ergonomic Foot-Pedal Control: Equipped with an intuitive foot pedal for quick, operator-friendly cycle triggering during manual or semi-automatic feeding.

• Versatile Processing Range: Easily handles workpiece diameters up to $\le \phi 300\text{ mm}$, heights up to $\le 150\text{ mm}$, and sheet metal thicknesses from 0.8 mm to 5 mm.

•


Industrial Applications

• Single-side handle hole and rivet hole punching on metal pots, pans, and kettles

• Stainless steel, aluminum, and brass container side-wall piercing

• Precision hole punching for hardware shells and cylindrical metal vessels

•


Frequently Asked Questions (FAQ)

Q1: What is the primary function of this machine?

A: It is designed for single-side hole punching, piercing, or pinching on the side walls of metal cookware and containers, typically for handle or rivet attachment.

Q2: What workpiece sizes can it handle?

A: It handles workpiece diameters up to $\le \phi 300\text{ mm}$, heights up to $\le 150\text{ mm}$, and material thicknesses from 0.8 mm to 5 mm.
