Product Description

The Electrolysis Machine is an advanced industrial system engineered specifically for the inner electrolysis polishing of bottles. Utilizing chemical liquids to polish the interior of containers, this machine features a 45-position layout, a turbo reducing gearbox for precise liquid filling, and adjustable stroke settings to accommodate different bottle heights while supporting manual continuous loading and unloading.

Key Machinery Features:

• Inner Electrolysis Polishing: Employs chemical liquid treatment to polish and smooth the inner side of metal bottles.

• 45-Position Design: Built with 45 working positions for high-volume, streamlined processing with simple operation.

• Turbo Reducing Gearbox Transmission: Utilizes a turbo reducing gearbox to achieve one-time liquid filling and adjustable stroke control based on varying bottle heights.

• Manual Continuous Operation: Designed for smooth manual placing and pickup of bottles during the production cycle.

Industrial Applications:

• Inner electrolysis polishing for stainless steel vacuum flasks and beverage bottles

• Surface finishing and electrochemical treatment for cylindrical metal container interiors

Technical Sections:

• Control & Power System: Operates via a CNC control method equipped with a high-frequency switching power supply (4000A, 18V), rated power of 74 kW, and rated voltage of 380V/415V.

• Structure & Capacity: Built with overall machine dimensions of 5800 x 1000 x 2500 mm and a net weight of 1800 kg. Accommodates pipe diameters from 30 to 120 mm, delivering a production capacity of 3,000 to 5,000 pcs per 10-hour shift.

•


Frequently Asked Questions (FAQ):

• Q: What is the main application of this machine?

• A: It is used for the inner electrolysis polishing of bottles.

• Q: What are the power specifications of the machine?

• A: It features a high frequency switching power supply of 4000A, 18V with a rated power of 74 kW.
