Product Description

The Auto. Feeder (2 pick 2push) / Double-table Loading Manipulator is a high-precision, 2-axis industrial automation manipulator engineered for continuous sheet metal loading in stamping, pressing, and deep drawing production lines. Featuring a double-table loading system, high-precision servo drive, Taiwan Yonghong PLC, and Shenzhen FanYi touch screen control, it achieves exceptional feeding accuracy (0.05 mm) and high production capacities up to 400-600 pcs/h without stopping for material replenishment.

Key Features & Highlights:

• Double-Table Continuous Feeding: Built with a double-table loading design (2 pick 2 push) to allow uninterrupted material feeding and seamless sheet reloading.

• High-Precision 2-Axis Servo Control: Driven by 2 axes (J1, J2) with Zhejiang Dongling servo motors, Laide precision gear rack, and Sanhuan guide rails, delivering feeding repeatability of 0.05 mm.

• Reliable Sheet Separation: Integrated with premium Haichen brand double sheet separation sensors to prevent multi-blank feeding and safeguard dies.

• Versatile Workpiece Handling: Handles round, square, and special/irregular sheet shapes ranging from 50 mm to 600 mm in size with a long forward/backward stroke of 1250 mm.

Industrial Applications: Widely applied in automated sheet metal stamping lines, cookware manufacturing (pots, pans, lids), hardware pressing, home appliance panel stamping, and high-efficiency automatic production lines.

Frequently Asked Questions (FAQ):

• Q: What is the main advantage of the double-table (2 pick 2 push) system?

  • A: The double-table system enables continuous loading without stopping the production line, significantly improving overall equipment efficiency (OEE).

• Q: What sheet sizes and shapes can this manipulator handle?

  • A: It supports round, square, and special/irregular shaped metal sheets in sizes ranging from 50 mm to 600 mm.
