Name: YDK Series Large Frame Type Hydraulic Press, Heavy Duty Hydraulic Press, Industrial Hydraulic Press Machine,Hydraulic Forming Press
Brand: SUZHOU BOARDING INDUSTRIAL CO. LTD.
Price: 60000 USD
Availability: InStock

Product Details:

Machine Type Mechanical Press
Technology Mechanical Stamping
Power Source Mechanical
Surface Treatment Standard
Type J21 Series Open Back Incline Press
Size 2323 3268 4216 mm
Material Steel
Share Your Product:

60000 USD ($)/Unit

Get a Price/Quote

Request To Call Back Send Inquiry

J21 Series Open Back Inclinable Press Price And Quantity

Price 60000 USD ($)/Unit
Price Range 1.00 - 10.00 USD ($)/Unit
Minimum Order Quantity 1 Unit

J21 Series Open Back Inclinable Press Product Specifications

Material Steel
Type J21 Series Open Back Incline Press
Length 2323 mm Millimeter (mm)
Product Type Open Back Incline Press
Power Source Mechanical
Surface Treatment Standard
Height 4216 mm Millimeter (mm)
Machine Type Mechanical Press
Size 2323 3268 4216 mm
Function Punching, blanking, cutting, bending, forming, drawing and stretching
Application Sheet Metal Stamping
Weight 33000 kg Kilograms (kg)
Technology Mechanical Stamping
Width 3268 mm Millimeter (mm)
Color Green

J21 Series Open Back Inclinable Press Trade Information

Payment Terms Letter of Credit at Sight (Sight L/C), Telegraphic Transfer (T/T)
Supply Ability 1-5 Unit Per Month
Delivery Time 60 Days
Sample Available Yes
Sample Policy Contact us for information regarding our sample policy
Packaging Details Standard export packaging with iron frame packaging
Main Export Market(s) Asia, Middle East, Africa
Main Domestic Market All India
Certifications Available upon request

Product Description

Technical Parameters:

Nominal Capacity : 4000 KN

Stroke of Slide : 200 mm

Stroke Per Minute : 30 s.p.m

Max. Shut Height : 550 mm

Shut Height Adjustment : 150 mm

Worktable Size : 4951350 mm

Worktable Hole Diameter : 280 mm

Thickness of Bolster : 200 mm

Column Spacing : 810 mm

Slide Bottom Size : 700600 mm

Shank Hole Diameter : 80 mm

Motor Power : 37 kW

Overall Dimensions : 232332684216 mm

Weight : 33000 kg

Tell us about your requirement

Price:

Quantity

Select Unit

50
100
200
250
500
1000+

Additional detail

Mobile number

Other Products in 'Deep Drawing Components' category

Cookware YD65 Four-column Hydraulic Deep Drawing Presses Price : 20000.00 USD ($)/Unit Minimum Order Quantity : 1 Width : 1600 mm Millimeter (mm) Automation Grade : Semi Automatic Warranty : 1 year Size : Standard Usage : Industrial Features : High rigidity fourcolumn structure, low energy consumption, adjustable pressure, stable operation, high efficiency, low noise Machine Type : Hydraulic Deep Drawing Press Application : Metal Containers, Kitchenware, Automotive Parts, Industrial Components Technology : Hydraulic Forming Technology Height : 5000 mm Millimeter (mm) Material : Steel Structure Voltage : 380V / 415V / Custom Volt (v) Product Type : YD65 Fourcolumn Hydraulic Deep Drawing Press Length : 5000 mm Millimeter (mm) Automatic Grade : SemiAutomatic Computerized : No Accuracy : High Precision % Color : Blue Accessories Type : Hydraulic System, Safety Protection Device, Control Panel Weight : 42000 kg Kilograms (kg) Function : Deep Drawing, Stamping, Pressing, Metal Forming Operating Pressure : 20 MPa mpa Control System : PLC Control System Surface Treatment : Paint Coating Type : Fourcolumn Hydraulic Press Power Source : Hydraulic
