Product Details:
- Accuracy High Precision %
- Machine Type Hydraulic Deep Drawing Press
- Technology Hydraulic Forming Technology
- Accessories Type Hydraulic System, Safety Protection Device, Control Panel
- Control System PLC Control System
- Operating Pressure 20 MPa mpa
- Features High rigidity four-column structure, low energy consumption, adjustable pressure, stable operation, high efficiency, low noise
Cookware YD65 Four-column Hydraulic Deep Drawing Presses Price And Quantity
- 20000.00 USD ($)/Unit
- 1 Unit
Cookware YD65 Four-column Hydraulic Deep Drawing Presses Product Specifications
- Hydraulic System, Safety Protection Device, Control Panel
- 1600 mm Millimeter (mm)
- PLC Control System
- 20 MPa mpa
- Standard
- 42000 kg Kilograms (kg)
- 5000 mm Millimeter (mm)
- Four-column Hydraulic Press
- Hydraulic
- 5000 mm Millimeter (mm)
- 380V / 415V / Custom Volt (v)
- High rigidity four-column structure, low energy consumption, adjustable pressure, stable operation, high efficiency, low noise
- Paint Coating
- Semi Automatic
- Deep Drawing, Stamping, Pressing, Metal Forming
- High Precision %
- Steel Structure
- Metal Containers, Kitchenware, Automotive Parts, Industrial Components
- Hydraulic Deep Drawing Press
- YD65 Four-column Hydraulic Deep Drawing Press
- Blue
- Industrial
- Hydraulic Forming Technology
Cookware YD65 Four-column Hydraulic Deep Drawing Presses Trade Information
- Shanghai
- Telegraphic Transfer (T/T)
- 1-5 Unit Per Month
- 45 Days
- Contact us for information regarding our sample policy
- 1. Machine is packed by steel Frame and wrapped with PE film for waterproof. 2.Spare parts will be packed by plywood carton. 3.Steel Size is according to machine size. 4.If special requests is need, kindly let us know.
- Asia, Middle East, Africa
- All India
- Available upon request
Product Description
Technical parameter:
YD65 Four-column Hydraulic Deep Drawing Press is designed for pressing, deep drawing, forming, and shaping various metal materials including aluminum, copper, iron, and stainless steel parts. It is widely used for manufacturing large vessels, tanks, water sinks, pots, vehicle covers, ship components, aerospace parts, and other industrial metal products.
The machine adopts a four-column structure with high rigidity and stable operation. It features low energy consumption, fast downward movement without loading, slow and controlled speed during pressing, high precision, and low noise operation.
Equipped with adjustable pressure control, adjustable stroke, position-limited ram protection, photoelectric safety protection, and automatic counting function, the YD65 Hydraulic Deep Drawing Press provides reliable performance, safe operation, and efficient production for various metal forming applications.
