Name: Y32-S Series Four Column Hydraulic Press
Brand: SUZHOU BOARDING INDUSTRIAL CO. LTD.
Price: 25000 USD
Availability: InStock

Multi-position Hydraulic Press (Special Machine for Filter Covers)

Product Details:

Nominal Force 650 kN
Usage Industrial
Power Source Hydraulic
Size Standard
Condition New
Dimension (L*W*H) According to model Millimeter (mm)
Height 1100 Millimeter (mm)
Share Your Product:

25000 USD ($)/Unit

Get a Price/Quote

Request To Call Back Send Inquiry

Multi-position Hydraulic Press (Special Machine for Filter Covers) Price And Quantity

Price 25000 USD ($)/Unit
Minimum Order Quantity 1 Unit

Multi-position Hydraulic Press (Special Machine for Filter Covers) Product Specifications

Motor Hydraulic Motor
Working Table Size 2200 mm 830 mm
Usage Industrial
Weight According to configuration Kilograms (kg)
Condition New
Power(W) 2500 W (Transfer Arm) Watt (w)
Nominal Force 650 kN
Height 1100 Millimeter (mm)
Dimension (L*W*H) According to model Millimeter (mm)
Product Type Multi-position Hydraulic Press
Size Standard
Voltage 415V Volt (v)
Length 5000 mm Millimeter (mm)
Width 2200 mm Millimeter (mm)
Power Source Hydraulic
PLC System PLC Control System
Max Opening Distance 300 mm Millimeter (mm)
Pressure Gauge 20 MPa
Color Custom

Multi-position Hydraulic Press (Special Machine for Filter Covers) Trade Information

FOB Port ShangHai
Payment Terms Telegraphic Transfer (T/T)
Supply Ability 1-5 Unit Per Month
Delivery Time 45 Days
Sample Available Yes
Sample Policy Contact us for information regarding our sample policy
Packaging Details Standard export packaging with iron frame and wooden case packaging.
Main Export Market(s) Africa, Asia, Middle East
Main Domestic Market All India
Certifications Available upon request

Product Description

Technical Specifications:

Designed specifically for filter cover production, this multi-position hydraulic press can save labor and space by completing several forming stages in a single press cycle. Featuring a stronger steel support device, closed-loop control system and advanced hydraulic control, it delivers high-precision pressing depth with tolerance within 0.02 mm, stable performance, low energy consumption and low noise. Available in three, four and five position configurations with optional automatic feeder and transfer arm.

Tell us about your requirement

Price:

Quantity

Select Unit

50
100
200
250
500
1000+

Additional detail

Mobile number

Other Products in 'Hydraulic Press' category

Cookware PLC Double Acting Hydraulic Deep Drawing Machines Price : 15000 USD ($)/Piece Minimum Order Quantity : 1 Voltage : 220240 Volt (v) Condition : New Product Type : Hydraulic Deep Drawing Machines Usage : Industrial Weight : 7800 Kilograms (kg) Power(W) : 22000 Watt (w) Height : 4000 Millimeter (mm) Color : Blue Working Table Size : 1000 mm x 1000 mm to 2500 mm x 2500 mm Nominal Force : 1600 kN to 4000 kN Dimension (L*W*H) : 2600*1900*4000 Millimeter (mm) Max Opening Distance : 1600 Millimeter (mm) Power Source : Hydraulic Size : Standard Pressure Gauge : Digital / Analog PLC System : Optional Width : 1900 Millimeter (mm) Motor : HighEfficiency Hydraulic Motor Drawing Material : MS Length : 1340 Millimeter (mm)
