Product Description

The Double Station Trimming Machine is a high-efficiency industrial metalworking solution engineered specifically for simultaneous trimming of bottle tops and bottoms. Equipped with an advanced PLC control and HMI screen interface, frequency-controlled spindle speeds, and four-axis combined running, this dual-station machine enables simultaneous processing on both ends of metal bottles with exceptional precision, fast operational speeds, and high throughput.

Key Machinery Features:

• PLC Control & HMI Operation: Features an intuitive PLC control system combined with an HMI touch screen and digital rotary switches for easy, full-function operation.

• Frequency Transducer Spindle Control: Spindle rotational speed can be adjusted at random and supports quick dynamic braking for enhanced safety and process control.

• Simultaneous Four-Axis Dual-End Trimming: Four-axis combined motion achieves simultaneous trimming of both ends of bottles at one time with stable performance and high output.

• Unified Frame with HGH Precision Rails: Built with a unified heavy-duty steel frame, top cylinder separated connection, and HGH high-precision linear guide rails for smooth loading, feeding, and unloading.

• Independent Double Stations: Dual-station architecture effectively doubles production capacity, with each station capable of operating independently for maximum operational flexibility.

Industrial Applications:

• Top and bottom trimming for stainless steel bottles, vacuum flasks, and metal containers

• Simultaneous dual-end edge cutting and finishing for metal tubes and shells

Technical Sections:

• CNC Servo & PLC Control System: Integrates precise CNC Servo Motor driving with an HMI interface to maintain tight cutting tolerances, fast cycle times, and repeatable accuracy.

• Heavy-Duty Construction & Efficiency Features: Designed with HGH precision guide rails, independent dual workstations, and quick brake control to minimize operator fatigue and downtime.

•


Frequently Asked Questions (FAQ):

• Q: What is the production capacity of this double station trimming machine?

• A: The machine delivers a high capacity of 8,00010,000 pcs per 10-hour shift.

• Q: Can the two stations operate independently?

• A: Yes, each station can work separately or together to match production demands.
