Product Description

The Bottom Disc Welding Machine is a high-precision industrial welding solution designed specifically for the welding of bottom discs onto bottle bodies. Powered by a PLC+HMI control system, stepper motor with reducing gearbox, and casting technology body frame, this machine ensures non-deforming structural stability and exceptional concentricity (00.04 mm) for high-speed laser or argon welding operations.

Key Machinery Features:

• PLC+HMI Control System: Features a clear, user-friendly touch screen page for simple and intuitive operation.

• Synchronized Precision Drive: Combines a stepper motor, reducing gearbox, and synchronizing wheel transmission for smooth, adjustable speed control.

• High-Precision Cast Body: The machine structure uses casting technology to provide enhanced steel performance, zero deformation, and tight concentricity of 00.04 mm.

• Simple Jig Design: Convenient fixture clamping and straightforward operation lower labor difficulty and setup time.

• Flexible Welding Support: Compatible with both laser welding and argon welding systems.

Industrial Applications:

• Welding bottom discs onto stainless steel vacuum flasks, bottles, and thermal containers

• Precision circular seam welding for metal containers and cylindrical bodies

Technical Sections:

• Control & Alignment Precision: Integrates a PLC (XIN JE) control system with pneumatic pressures between 0.4 and 0.6 MPa, guaranteeing tight concentricity tolerance (00.04 mm) during automated rotation.

• Compact Footprint & High Output: Features a compact machine dimension of 1000 x 600 x 2000 mm, a net weight of 200 kg, low rated power of 0.2 kW, and an impressive capacity of 8,00010,000 pcs per 10-hour shift.

•


Frequently Asked Questions (FAQ):

• Q: What welding methods can be used with this machine?

• A: It supports both laser welding and argon welding configurations.

• Q: What is the concentricity precision of this machine?

• A: The casting technology body maintains high accuracy with a concentricity tolerance between 0 and 0.04 mm.
