Product Description

The Hydraulic Pipe Cutting Machine is a semi-automatic high-efficiency cutting unit designed to divide long metal pipes into shorter segments. Equipped with a PLC control system for easy operation, it features a sliding rail tooling support capable of cutting pipes with diameters from 30 mm to 150 mm and lengths from 80 mm to 750 mm. Designed with safety photoelectric protectors, a special tail support for accurate pipe positioning, and a powerful hydraulic pressing system, this compact machine delivers a daily production capacity of 8,00010,000 pieces per 10 hours at a low rated power of 2.6 kW.

Key Features & Highlights:

• PLC Automated Control: Easy operation with user-friendly PLC interface, reducing manual technical operator requirements.

• Sliding Rail Tooling Support: Smooth sliding mechanism suitable for cutting flask liners and SS pipes.

• Safety Photoelectric Sensor: Rear-mounted photoelectric protection system stops machine operation immediately upon obstruction to protect operator safety.

• Tail Support & Precision Clamping: Tail support holds pipes securely, ensuring effortless material loading and precise cutting lengths.

• Hydraulic Pressing Efficiency: Dedicated hydraulic pressing mechanism guarantees strong clamping force and high-quality cut edges.

Industrial Applications: Widely applied in cutting, trimming, and sizing stainless steel tubes, thermos flask liners, travel mug bodies, and cylindrical hardware containers.

Frequently Asked Questions (FAQ):

• Q: What pipe dimensions can Model SZBD-02-FLK process?

• A: It handles pipe diameters of 30150 mm, pipe lengths of 80750 mm, and wall thicknesses of 0.30.8 mm.

• Q: What is the daily output capacity of this machine?

• A: It achieves a high output of 8,00010,000 pcs per 10-hour shift.
