Product Description

HPD Series Closed Type High Precision Press is a high-rigidity precision stamping press designed for sheet metal forming and stamping applications. It is suitable for electronics, electrical appliances, furniture, vehicles, hardware, and related industries. The press features a heat-treated and stress-relieved frame, balanced center of gravity, slide balancer, hardened crankshaft and gears, and semi-enclosed structure for improved stamping stability and precision.

Technical Parameters:

Capacity : 200 T

Striking Point : 6 / 3 mm

Stroke : 200 / 100 mm

Open Height : 460 / 510 mm

Stroke Per Minute : 2050 / 5070 s.p.m.

Slide Adjustment : 110 mm

Slide Area : 850 630 90 mm

Bolster Area : 1140 820 160 mm

Main Power : VS18 4 kW

Overall Dimension : 1750 2500 3900 mm

Weight : 25.3 T

Air Pressure : 6 kg/cm

Die Cushion Capacity : 14 T

Die Cushion Stroke : 100 mm

Die Cushion Effective Area : 710 480 mm

Pressure Precision : GB (JIS) 1 Class
