The Feeder Machine / Single-side Ground Lifting Loading Manipulator is a high-performance 4-axis industrial automation feeder engineered for automated sheet metal pickup and loading in stamping, deep drawing, and pressing production lines. Powered by 220V single-phase power, Dongling servo motors, Taiwan Yung-Hong controller, and Fanyi touchscreen, it features integrated surface oiling adjustment and Haichen intelligent double sheet detection to streamline sheet feeding with precision and reliability.

Key Features & Highlights:

• Flexible 4-Axis Servo Control: Features 4 motion axes (J1/J2/J3/J4) driven by Dongling servo motors and Sanhuan guide rails, providing long forward/backward and left/right strokes of 1250-1000 mm with precision repeatability (+0.05 mm).

• Integrated Oiling & Flow Adjustment: Built with on-circle oil lubrication capabilities and adjustable oil flow control to protect sheet metal and dies during press operations.

• Intelligent Double Sheet Protection: Equipped with a Haichen Intelligent Double Sheet Detector to prevent multi-blank loading and protect stamping tooling.

• Wide Sheet Handling Capability: Supports circular blanks and metal sheets ranging from 200 mm to 1200 mm in size, with a maximum circle weight allowance under 10 kg.

•


Industrial Applications: Ideal for automated sheet metal stamping lines, cookware manufacturing (pots, pans, lids), hardware presses, home appliance panel fabrication, and automated stamping cells.

Frequently Asked Questions (FAQ):

• Q: What is the maximum blank size and weight this single-side lifting manipulator can handle?

  • A: It handles sheet sizes from 200 mm up to 1200 mm, with a maximum workpiece weight capacity of up to 10 kg.

• Q: Does this machine support lubrication during the loading process?

  • A: Yes, it features integrated oil lubrication on circles with adjustable oil flow control.
