Product Description

Hydraulic Water Bulging Machine for Metal Pipe Hydroforming & Shape Forming

Introduction: The Hydraulic Water Bulging Machine is a high-performance hydroforming system engineered for forming complex pipe shapes through ultra-high liquid pressure. Controlled by an industrial microcomputer Servo PLC system, this heavy-duty machine operates at a max working pressure of 20 MPa and a water cylinder pressure of 80160 MPa. Featuring 1250 KN top cylinder force, 1250 KN booster force, and fast-downward/slow-pressing motions, it enables simultaneous multi-piece processing with high precision, low energy consumption, and low operating noise.

Key Features & Highlights:

• Servo PLC Microcomputer Control: User-friendly operation with highly accurate pressure and stroke control.

• High Efficiency Multi-Piece Forming: Capable of forming multiple workpieces in a single cycle for maximum throughput.

• Optimized Speed Sequence: Fast downward movement under no-load, smooth slow-speed closing and pressing, and rapid upward return (up to 400 mm/s).

• Energy-Efficient & Low Noise: Advanced hydraulic design reduces energy consumption and noise during heavy-duty operation.

•


Industrial Applications: Extensively used in hydroforming thermos cup/flask bodies, stainless steel teapots, sanitary fittings, shaped metal tubes, automotive pipe components, and complex hollow containers.

Frequently Asked Questions (FAQ):

• Q: What is the maximum water cylinder pressure for Model SZBD-05-FLK?

• A: It delivers an ultra-high water cylinder pressure range of 80160 MPa.

• Q: What is the total motor power requirement for this machine?

• A: The machine requires a total motor power of 25 kW (22 kW + 3 kW).
