Name: 650T Downward Moving Large Frame Hydraulic Press
Brand: SUZHOU BOARDING INDUSTRIAL CO. LTD.
Price: 50000 USD
Availability: InStock

Cookware Six-Axis Servo Three Stations Turning Beading Pressing and Trimming Machine

Product Details:

Polish Type Other
Finish Type Glossy, Semi-Gloss, Matte
Power Source Electric
Accessories CNC Servo Control Panel, Servo Actuators, Tool Holders, Fixture Assembly Finish Type: Smooth Cut / Formed Rim / Beaded Edge
Application Areas Industrial
Application Surface Stainless Steel / Aluminum / Sheet Metal Edges & Rim Boundaries
Form Vertical Cabinet Frame / Three Station Multi-Axis
Share Your Product:

50000 USD ($)/Set

Get a Price/Quote

Request To Call Back Send Inquiry

Cookware Six-Axis Servo Three Stations Turning Beading Pressing and Trimming Machine Price And Quantity

Price 50000 USD ($)/Set
Minimum Order Quantity 1 Set

Cookware Six-Axis Servo Three Stations Turning Beading Pressing and Trimming Machine Product Specifications

Application Areas Industrial
Warranty 1 Year
Capacity 3 Pcs/min
Form Vertical Cabinet Frame / Three Station Multi-Axis
Material Heavy Duty Steel Frame / Precision CNC Mechanical Components
Application Surface Stainless Steel / Aluminum / Sheet Metal Edges & Rim Boundaries
Color Blue
Power Source Electric
Finish Type Glossy, Semi-Gloss, Matte
Accessories CNC Servo Control Panel, Servo Actuators, Tool Holders, Fixture Assembly Finish Type: Smooth Cut / Formed Rim / Beaded Edge
Polish Type Other
Thickness 250 Millimeter (mm)
Air Pressure 0.6 mpa
Automatic Grade Semi-Automatic
Size N/A
Power 11800 Watt (w)
Type Six-Axis Servo Turning Beading Pressing & Trimming Machine / Cookware Edge Processing Machine
Usage & Applications Turning, rim beading, edge pressing, and trimming for cookware and metal bodies
Computerized Yes
Voltage 380 Volt (v)
Grade Standard Industrial Grade
Heating System N/A
Melting Point N/A
Weight 3200 Kilograms (kg)

Oil Tank Capacity 1200 L
Cycle Time 22 s
Application Forming, stamping, deep drawing, and molding operations
Stroke of Slide 800 mm
Return Speed 80 mm/s
Machine Weight Approx. 25,000 kg
Safety Features Light curtain, emergency stop, safety interlock
Control System Automatic and manual modes
Frame Structure Four-column, large frame
Hydraulic Oil Type 46# anti-wear hydraulic oil
Approach Speed 120 mm/s
Working Pressure 25 MPa

Cookware Six-Axis Servo Three Stations Turning Beading Pressing and Trimming Machine Trade Information

Payment Terms Telegraphic Transfer (T/T)
Supply Ability 1-5 Set Per Month
Delivery Time 20 Days
Sample Policy Contact us for information regarding our sample policy
Packaging Details Standard export packaging with wooden case / iron frame packaging.
Main Export Market(s) Asia, Middle East, Africa
Main Domestic Market All India
Certifications Available upon request

Product Description

The Six-axis servo three stations turning beading pressing and trimming machine is a high-precision metal forming unit designed for integrated post-forming processes on cylindrical cookware and hardware products. Equipped with a 4 kW main workpiece motor and six 1.3 kW servo motors, it drives three specialized stations to execute turning, rim beading, edge pressing, and excess material trimming within a single machine layout. Accommodating workpiece diameters from 160 mm to 380 mm and heights up to 250 mm, it significantly reduces manual handling and boosts automated production line efficiency.

Key Features & Highlights:

Six-Axis Servo Control: Features six 1.3 kW high-precision servo motors for multi-axis coordinated control, accurate tool positioning, and repeatable forming accuracy.
Three-Station Multi-Function Operations: Integrates turning, beading, pressing, and trimming into three processing stations for complete edge finishing.
Wide Processing Capability: Accommodates cookware and metal container diameters from 160 mm to 380 mm, with heights up to 250 mm.
Variable Spindle Speed: Driven by a 4 kW main motor operating at adjustable rotation speeds between 100 rpm and 500 rpm.

Industrial Applications: Widely used for edge trimming, rim curling/beading, bottom pressing, and surface turning of stainless steel pots, saucepans, stockpots, kettles, thermos liners, and metal containers.

Frequently Asked Questions (FAQ):

Q: What is the processing workpiece range for Model DHCJYX-316?
A: It processes workpieces with diameters ranging from 160 mm to 380 mm and maximum heights up to 250 mm.
Q: What is the power configuration of the servo system?
A: It is equipped with six 1.3 kW servo motors along with a 4 kW main workpiece motor.
