Product Description

The Horizontal Circular Welding Machine is a heavy-duty industrial welding solution engineered for high-precision circular seam welding. Built with a stable horizontal body frame, integrated PLC control, stepper motor drive, and fine-tunable welding gun positioning, this versatile machine supports both argon arc and laser welding options to deliver clean, highly consistent circumferential welds.

Key Machinery Features:

• PLC Integrated Control: Features a centralized PLC system for simple, stable, and accurate machine operation.

• Horizontal Machine Structure: Rigid horizontal layout ensures structural stability and consistent weld quality across long workpieces.

• Semi-Automatic Operation: Manual loading/unloading paired with automatic welding processes for optimal operational speed.

• Precision Spindle & Clamping: Stepper motor with reducer drives smooth spindle rotation, easy clamping pressure adjustment, and simple fixture operation.

• Fine-Tuning Gun & Arc Protection: Includes an angle-adjustable welding gun fine-tuning mechanism and automatic arc-blocking safety goggles.

Industrial Applications:

• Circular seam welding for stainless steel pipes, tubes, flasks, and cylinders

• Precision circumferential joining for metal containers and industrial pipe fittings

Technical Sections:

• Automation & Drive Control: Utilizes PLC logic with a stepper motor and reducer to deliver smooth speed control, reliable pneumatic pressure (0.40.6 MPa), and adjustable spindle clamping.

• Capacity & Structural Dimensions: Features a compact horizontal footprint (1800 x 600 x 1050 mm) and 1.5 kW rated power, supporting pipe diameters of 30200 mm and lengths up to 450 mm with a daily production capacity of 2,5003,500 pcs/shift.

•


Frequently Asked Questions (FAQ):

• Q: What welding methods are supported by this horizontal machine?

• A: It offers flexible configuration options for either Argon Arc Welding or Laser Welding.

• Q: What range of pipe diameters and lengths can it handle?

• A: It supports pipe diameters from 30 mm to 200 mm and pipe lengths from 0 mm up to 450 mm.
