Product Description

The Sand Blasting Machine is a high-efficiency surface preparation system designed specifically as a pre-electrolysis treatment solution. Powered by compressed air, the machine pressurizes abrasive media in the tank, feeding it through a specialized sand valve and nozzle to blast the workpiece surface for thorough cleaning and finishing. Featuring a dual-piece simultaneous blasting design, an integrated dust collection chamber, and low power consumption, it achieves exceptional daily production capacity for industrial container processing.

Key Machinery Features:

• Compressed Air Blasting System: Utilizes compressed air to force abrasive material through sand conveying pipes and eject it via nozzles for effective surface cleaning.

• Dedicated Dust Collection Chamber: Equipped with an integrated sand dust collecting chamber (510 x 510 x 800 mm) to ensure a clean working environment.

• Energy-Efficient Operation: Engineered for low power consumption while maintaining heavy-duty industrial cleaning standards.

• Dual-Piece Simultaneous Blasting: Processes 2 pieces in 1 machine at the same time to optimize operational output.

• High Production Efficiency: Delivers high output with 6,0008,000 pcs finished in 1 day (8 hours) and up to 8,00010,000 pcs per 10-hour shift.

Industrial Applications:

• Surface cleaning and preparation before electrolysis for inner bottles, flasks, and metal containers

• Abrasive surface roughening, rust removal, and scale cleaning for cylindrical metal parts

Technical Sections:

• Pneumatic Drive & Dust Extraction: Controlled by a dedicated JEG CONTROLLER operating at pneumatic pressures of 0.40.6 MPa. Equipped with dual rotary motors (200W x 2) and a 550W dust catcher for efficient abrasive rotation and dust extraction.

• Structure & Capacity: Features a machine dimension of 1100 x 800 x 2000 mm, air cylinder stroke of 250 mm, and total rated power of 2.5 kW. Supports 2 pcs simultaneous processing, reaching a capacity of 8,00010,000 pcs per 10-hour shift.

•


Frequently Asked Questions (FAQ):

• Q: What is the main application of this sand blasting machine?

• A: It is used as a surface cleaning and preparation solution before electrolysis.

• Q: How many pieces can be processed at the same time?

• A: The machine finishes 2 pieces simultaneously in a single operation.
