Product Description

The Copper Plating Line is an advanced automated surface treatment production system designed for the outer surface copper plating of inner bottles. By applying a precision copper layer, this machine significantly improves the thermal insulation performance of vacuum flasks compared to traditional aluminum foil wrapping. Featuring an automated overhead chain and rail convey system, workers only need to handle loading and unloading while all process steps are automatically finished by the machine.

Key Machinery Features:

• Enhanced Thermal Insulation: Enhances insulation performance through precise copper electroplating process.

• Superior to Aluminum Foil: Provides more advanced and stable product performance compared to traditional aluminum foil packaging methods.

• Easy & Efficient Operation: High degree of automation where workers only need to load and unload workpieces while the machine automatically completes the plating cycle.

• High Batch Capacity: High production throughput capable of finishing 200 pcs simultaneously in a single machine run.

Industrial Applications:

• Outer surface copper plating for inner bottles of stainless steel vacuum flasks

• Automated electroplating and thermal barrier coating for metal containers

Technical Sections:

• Power Supply & Drive Control: Utilizes motor driving for conveyor motion paired with high-frequency power sources (12V-1500A and 12V-3000A) and 500 pcs conducting copper heads to ensure consistent electroplating current.

• Tank Configuration & Capacity: Integrates a multi-stage process line including water filling tank (1pc, 3M), nickel tank (1pc, 6M), water washing tanks (3pc, 1M), acid copper tank (1pc, 26M), passivating tank (1pc, 3.5M), and item removing tank (1pc). The overall line dimension is 26000 x 2000 x 2000 mm with 50 kW total power.

•


Frequently Asked Questions (FAQ):

• Q: What is the main application of this copper plating line? A: It is used for the outer surface copper plating of inner bottles to improve thermal insulation.

• Q: How many pieces can be plated simultaneously in one machine batch? A: The machine can process 200 pcs at the same time.
