Product Description

The Two Head Vertical CNC Sanding Machine is a high-precision numerical control surface treatment unit designed for both inside and outside belt sanding of round metal products. Powered by a 5.5 kW workpiece motor with variable speed control (2001400 rpm), dual 2.5 kW servo motors, and a 7.5 kW converter, it efficiently processes workpieces up to 500 mm in diameter and 400 mm in height. The dual-station vertical configuration delivers flexible, precise, and uniform surface grinding for mass production lines.

Key Features & Highlights:

• CNC Precision Control: Driven by dual 2.5 kW servo motors for precise tool positioning, multi-axis control, and consistent surface finish quality.

• Inside & Outside Sanding Capabilities: Accommodates inside sanding diameters from 120 mm to 500 mm, and outside sanding diameters up to 500 mm.

• Flexible Speed Adjustment: Features a 5.5 kW workpiece motor running at variable spindle speeds between 200 and 1400 rpm, supported by a 7.5 kW frequency converter.

• Substantial Workpiece Height: Supports tall cylindrical components with maximum heights up to 400 mm.

Industrial Applications: Widely applied for internal and external surface sanding, deburring, satin finishing, and pre-polishing of stainless steel pots, soup kettles, stockpots, frying pans, cylinders, and round metal cookware.

Frequently Asked Questions (FAQ):

• Q: What are the workpiece processing size ranges for Model DHSG-500?

• A: It supports inside sanding diameters of 120500 mm, outside sanding diameters up to 500 mm, and maximum workpiece heights up to 400 mm.

• Q: What is the motor and power configuration of this machine?

• A: It features a 5.5 kW workpiece motor, dual 2.5 kW servo motors, and a 7.5 kW frequency converter.
