Product Details:
- Accessories Polishing Wheel Mounts, Workpiece Fixtures, Control Panel
- Form Cabinet Frame / Dual Station
- Power Source Electric
- Finish Type Glossy, Semi-Gloss, Matte
- Application Areas Industrial
- Power 23100 Watt (w)
- Usage & Applications External surface polishing and mirror finishing for cookware, pots, and metal bodies
Double-Head Outside Polishing Machine Price And Quantity
- 30000 USD ($)/Set
- 1 Set
Double-Head Outside Polishing Machine Product Specifications
- Stainless Steel / Aluminum / External Metal Walls
- Other
- 1 Year
- 280 Millimeter (mm)
- Semi-Automatic
- 0.6 mpa
- Heavy Duty Steel Frame / Alloy Structural Components
- Industrial Grade
- 23100 Watt (w)
- 2 Pcs/min
- External surface polishing and mirror finishing for cookware, pots, and metal bodies
- N/A
- Double-head Outside Polishing Machine / External Wall Polisher
- Industrial
- Electric
- Glossy, Semi-Gloss, Matte
- Cabinet Frame / Dual Station
- 380 Volt (v)
- 3000 Kilograms (kg)
- Blue
- Yes
- N/A
- Polishing Wheel Mounts, Workpiece Fixtures, Control Panel
- Energy Efficient with Overload Protection
- 1100 L
- 400 mm
- Touch Screen HMI
- Four Column Rigid Steel Construction
- Low Noise Operation (<75 dB)
- Approx. 15 Ton
- Automotive, Electrical, Hardware Fineblanking
- Built-in Heat Exchanger
- 30 mm/s
- Dual Hand Operation, Emergency Stop
- 8-15 mm/s
- 0.1 mm
Double-Head Outside Polishing Machine Trade Information
- Telegraphic Transfer (T/T)
- 1-5 Set Per Month
- 20 Days
- Contact us for information regarding our sample policy
- Standard export packaging with wooden case / iron frame packaging.
- Africa, Asia, Middle East
- All India
- Available upon request
Product Description
The Double-head Outside Polishing Machine is a high-efficiency dual-station surface finishing unit engineered for mass outer-wall polishing of cylindrical metal products. Powered by two 11 kW high-torque polishing motors and dual 0.55 kW workpiece drive motors, it easily accommodates workpieces up to 400 mm in diameter and 300 mm in height. Operating at a main spindle speed of 2200 rpm with adjustable workpiece rotation (28140 rpm), it delivers consistent, high-gloss mirror finishes across industrial manufacturing lines.
Key Features & Highlights:
-
Dual High-Power Polishing Heads: Equipped with two independent 11 kW main polishing motors (22 kW total polishing power) for dual-station or two-stage outer wall polishing.
-
Independent Workpiece Drives: Driven by two 0.55 kW workpiece motors with variable rotation speeds ranging from 28 to 140 rpm for optimized surface uniformity.
-
Large Workpiece Capacity: Capable of handling large cylindrical metal containers up to 400 mm in diameter and 300 mm in height.
-
Heavy Wheel Compatibility: Supports large polishing wheels up to 450 mm in diameter and 280 mm in width/thickness for extended service life and smooth coverage.
-
Industrial Applications: Widely used for external surface polishing, deburring, and high-gloss mirror finishing on stainless steel cookware, soup pots, stockpots, frying pans, buckets, kettles, and round metal hardware containers.
Frequently Asked Questions (FAQ):
-
Q: What is the maximum workpiece size this double-head outside polishing machine can process?
-
A: It can process workpieces with maximum dimensions of 400 mm in diameter and 300 mm in height.
-
Q: What are the motor configurations for Model DHWP-400?
-
A: It features two 11 kW main polishing motors and two 0.55 kW workpiece motors.
