Product Description

The Bottom, outside body polishing machine is an efficient surface processing unit designed for polishing both the bottom and side surfaces of metalware components. Driven by 7.5 kW and 4 kW polishing motors, a 0.37 kW compensation motor, and a 0.55 kW workpiece driving motor, it can handle workpieces up to 300 mm in diameter and 60 mm in height. The dual-head mechanism provides precise, simultaneous or sequential polishing, making it an ideal choice for mass-producing high-gloss metal products.

Key Features & Highlights:

• Dual Polishing Motors: Configured with two high-performance polishing motors (7.5 kW and 4 kW) operating at spindle speeds of 2200 rpm and 2900 rpm.

• Automatic Compensation Control: Integrated with a 0.37 kW compensation motor to maintain constant polishing pressure and wheel wear adjustment.

• Workpiece Rotation Drive: Driven by a 0.55 kW workpiece motor at a rotation speed of 56 rpm for uniform circumferential polishing.

• Compact Product Accommodation: Engineered for shallow cylindrical components with diameters up to 300 mm and heights up to 60 mm.

Industrial Applications: Widely applied for external surface finishing, bottom polishing, and outer wall polishing of stainless steel frying pans, pan covers, shallow pots, trays, hardware accessories, and round metal components.

Frequently Asked Questions (FAQ):

• Q: What is the maximum workpiece dimensions supported by the DHDC-231 model?

• A: It supports workpieces with a maximum diameter of 300 mm and a maximum height of 60 mm.

• Q: What are the motor power ratings for this dual-head machine?

• A: The main polishing motors are rated at 7.5 kW and 4 kW, complemented by a 0.37 kW compensation motor and a 0.55 kW workpiece motor.
