C-Shape Ring Making Machine
Product Details:
- Phase Single/Three Phase
- Shape C-Shape Rings
- Torque Adjustable Drive Torque
- Diameter 10 mm to 50 mm
- Product Type C-Shape Ring Making Machine
- General Use For making C-type rings from metal wires
- Material Mild Steel (Body), High Carbon Steel (Forming Die)
15000 USD ($)/Set
X
C-Shape Ring Making Machine Price And Quantity
- 15000 USD ($)/Set
- 1 Set
C-Shape Ring Making Machine Product Specifications
- Semi-automatic/Automatic options
- Available on request
- Wire Forming Machine
- 220-415 V
- PLC Control
- Single/Three Phase
- In-line quality checks available
- 1800 mm x 950 mm x 1450 mm
- Adjustable Drive Torque
- 10 mm to 50 mm
- Yes
- C-Shape Rings
- 0.1 mm
- High efficiency, Easy operation, Consistent output
- Polished/Painted
- C-Shape Ring Making Machine
- Mild Steel (Body), High Carbon Steel (Forming Die)
- Approx. 800 kg
- Yes
- For making C-type rings from metal wires
- 30-60 pcs/min
- Industrial Blue/Grey
C-Shape Ring Making Machine Trade Information
- 1-5 Set Per Month
- 7-15 Days
Product Description
This C-shape ring making machine finds its application in manufacturing, woodworking, metalworking and other related industries. Provided machine is used for making c-shape ring on hard workpiece. Offered machine has features such as model ZKD-40007, overall size (mm) 650 x 780 x 1750mm and max diameter of ioop- forming Ø400mm. Due to its hassle free working, minimum maintenance and robustness, provided machine is highly cherished among clients across world. This machine is manufactured using quality approved components by our skilled professionals. Apart from this, offered C-shape ring making machine is available for our clients in numerous specifications as per their requirements.
Technical Specifications:
| Model | Overall size | Max diameter of ioop- forming | Power | voltage |
| ZKD-40007 | 650 x 780 x 1750mm | 400mm | 0.75 KW | 380V |
Precision Engineering for C-Shaped Ring Production
Designed to cater to manufacturers, distributors, and suppliers, this machine produces C-shape rings with an impressive 0.1 mm tolerance. Its adjustable drive torque and in-line QC system ensure product conformity for industrial applications.
Automated and User-Friendly Operation
With automated wire feeding, pneumatic cutting, and touch screen PLC controls, the machine streamlines ring production. The semi-automatic or fully automatic modes enable swift switching based on operational needs, handled effortlessly by a single operator.
Durable Construction and Efficient Output
Constructed with a corrosion-resistant polished or painted mild steel body and forming die of high carbon steel, the machine ensures longevity. Its high efficiency allows up to 3600 pieces per hour, providing a scalable solution for high-volume output.
FAQs of C-Shape Ring Making Machine:
Q: How does the automatic wire feeding system of the C-Shape Ring Making Machine enhance production efficiency?
A: The automatic wire feeding system consistently supplies metal wire to the forming section, reducing manual effort and increasing continuous output. This results in higher production speeds and ensures uniform ring formation.Q: What materials are suitable for use with this ring making machine?
A: The machine is constructed to form C-shape rings from various metal wires, with the body made of mild steel and the forming die crafted from high carbon steel. It efficiently processes wire diameters between 2 mm and 6 mm.Q: What is the typical installation process for this machine, and where can it be implemented?
A: Professional installation services are available, ensuring the machine is set up safely and correctly. It can be installed in manufacturing facilities, workshops, or export centers, requiring access to a 220-415 V power supply.Q: How does the pneumatic cutting system work in the wire ring forming process?
A: The pneumatic cutting system uses compressed air to power precise wire cuts after each ring is formed, offering faster and cleaner cuts compared to mechanical alternatives. This enhances consistency and minimizes waste.Q: What are the benefits of the touch screen PLC control system for machine operation?
A: The touch screen PLC control system provides intuitive operational access and real-time monitoring. It enables quick parameter adjustments, simplifies troubleshooting, and enhances productivity through its computerized automation.Q: When are spare parts provided, and what support is included?
A: Spare parts for routine maintenance are included for the first year of operation. This provision reduces downtime and ensures uninterrupted productivity during the initial operational period.Q: What quality control features are integrated into the C-Shape Ring Making Machine?
A: The machine features an in-line QC system that monitors the size and shape of each ring produced to maintain strict quality standards. Tolerance is assured at 0.1 mm, yielding reliable and consistent results.Tell us about your requirement
