Portuguese1200T Large Frame Cold Extrusion Machine
Product Details:
- Nominal Force 12000 kN (1200 Ton)
- Power Source Electric
- Condition New
- Dimension (L*W*H) 4300 x 1600 x 3550 mm
- Power(W) 45 kW
- Voltage 380 V / 50 Hz
- Motor High-Efficiency AC Motor
50000 USD ($)/Set
X
1200T Large Frame Cold Extrusion Machine Price And Quantity
- 1 Set
- 50000 USD ($)/Set
1200T Large Frame Cold Extrusion Machine Product Specifications
- 380 V / 50 Hz
- 1100 x 1000 mm
- New
- Electric
- Included
- Digital & Analog Available
- 12000 kN (1200 Ton)
- Siemens PLC Control
- 1200 mm
- 45 kW
- 4300 x 1600 x 3550 mm
- Integrated
- High-Efficiency AC Motor
- Included
1200T Large Frame Cold Extrusion Machine Trade Information
- 1-5 Set Per Month
- 7-15 Days
Product Description
ZY34-1200T Large Frame Cold Extrusion Machine
| Items | Machine Models | ||||||||
|
| Unit | ZY34-100 | ZY34-200 | ZY34-300 | ZY34-500 | ZY34-800 | ZY34-1000 | ZY34-1500 | ZY34-2000 |
| Rated Pressure | KN | 1,000 | 2,000 | 3,000 | 5,000 | 8,000 | 10,000 | 15,000 | 20,000 |
| Max.working pressure | Mpa | 20 | 23 | 23 | 24 | 24 | 26 | 20 | 20 |
| Max.stroke | mm | 160 | 160 | 160 | 160 | 160 | 160 | 160 | 160 |
| Max.Daylight | mm | 350(500) | 400(600) | 450#650 | 550(800) | 550(1000) | 600(1000) | 700(1200) | 800(1200) |
| Upward speed of ram | mm/s | 200 | 200 | 200 | 200 | 200 | 200 | 200 | 200 |
| Speed of pressing | mm/s | 6/12 | 4/10 | 3/6 | 3/7 | 2/5 | 3/7 | 2/5 | 2/5 |
| Speed of return | mm/s | 200 | 200 | 200 | 200 | 200 | 200 | 200 | 200 |
| Real working table size | mm | 420*420 | 500*520 | 580*580 | 700*700 | 750*750 | 900*900 | 920*920 | 1150*1150 |
| Height between working table and ground | mm | 900 | 950 | 990 | 1,100 | 1,200 | 1,400 | 1,580 | 1,700 |
| Overall dimension(LR*FB*H) | mm | 900*950*1200 | 1100*1000*1400 | 1150*1100*1500 | 1300*1200*1750 | 1400*1300*1850 | 1500*1500*2800 | 1680*2000*3000 | 2000*2000*3200 |
| Motor Power | KW | 5.5 | 7.5 | 7.5 | 15 | 18.5 | 22 | 37 | 45 |
| Max.pressure of supercharger | Mpa |
|
|
|
|
|
| 39 | 39 |
| Machine Weight | T | 2 | 2.8 | 3.5 | 6 | 12 | 16 | 19 | 24 |
High-Capacity Hydraulic Cold Extrusion
The machine delivers powerful cold extrusion forming at up to 12000 kN, streamlining the production of metal parts, fasteners, and auto components. Its large welded steel frame ensures durability and repeatable accuracy, supporting the rigorous demands of automotive and metalworking sectors. With a rapid cycle time of 15-20 seconds per operation, manufacturers benefit from increased productivity and superior part consistency.
Advanced Control & Safety Features
Equipped with a Siemens PLC system, operators can manage and monitor the press with an intuitive touch screen alongside manual buttons, ensuring flexible and reliable operation. Comprehensive safety measuresincluding emergency stop, safety interlock systems, and a light curtainprotect operators during each cycle, while digital and analog pressure gauges keep system conditions in check.
Optimized Efficiency & Maintenance
The machine integrates a high-efficiency AC motor and automatic centralized lubrication, reducing downtime and maintenance costs. Its substantial oil tank capacity of 1800 liters and integrated proportional, solenoid, and pre-fill valves guarantee smooth performance. The industrial blue finish is customizable, allowing manufacturers to match their branding needs.
FAQs of 1200T Large Frame Cold Extrusion Machine:
Q: How does the 1200T Large Frame Cold Extrusion Machine improve production efficiency in the automobile industry?
A: By delivering a nominal force of 1200 tons and a fast cycle time of 15-20 seconds, this hydraulic press accelerates the manufacturing of metal auto components, reducing lead times and enhancing throughput across large-scale industrial operations.Q: What safety features are incorporated into this hydraulic cold extrusion press?
A: The machine is equipped with an emergency stop system, safety interlock, and a light curtain to protect operators. These features ensure immediate shutdown and prevent accidental access during operation for maximum workplace safety.Q: When is routine maintenance required for the lubrication system?
A: Thanks to its automatic centralized lubrication system, routine maintenance intervals are minimized; however, its recommended to check lubrication flow and replenish oil as indicated by production usage or the systems alerts to ensure ongoing optimal performance.Q: Where can this cold extrusion machine be installed, and what are its power requirements?
A: The machine is suitable for installation in industrial production facilities and factory floors. It requires an electric power supply of 380V/50Hz and consumes up to 45 kW, with additional infrastructure needed for its approximate weight of 42,000 kg.Q: What types of metal parts and components can be processed using this machine?
A: It is designed for a range of applications including fasteners, auto components, and various metal parts, making it highly versatile for the automobile and metalworking industries.Q: How is the control system designed to facilitate operation and monitoring?
A: A Siemens PLC system coordinates the hydraulic press, offering both touch screen controls and manual buttons, enabling easy setup, real-time monitoring, and adaptability during production cycles.Q: What advantages does the large welded steel frame provide for cold extrusion applications?
A: The robust frame construction ensures minimal flex and vibration, maintaining precise alignment and consistent force application for high-quality cold extrusion results in demanding manufacturing environments.Tell us about your requirement
