YZ28G-K FAST PRESSING HYDRAULIC PRESS

YZ28G-K FAST PRESSING HYDRAULIC PRESS
YZ28G-K FAST PRESSING HYDRAULIC PRESS
Product Code : 05
Product Description

Technical Specifications:

Item

Unit

YZ8G-120 K1

YZ8G-120 K2

YZ8G-200K

YZ8G-280K

YZ8G-350K

Nominal Capacity

Kn

760

900

1500

2000

2500

Nominal working pressure of hydraulic

Mpa

20

20

20

21

21

Return capacity

kN

50

300

120

140

140

Cushion cylinder capacity

kN

350

300

500

1000

100

Cushion cylinder max. Pressure

Mpa

20

20

20

26

26

Max. Stroke of piston

mm

200

250

300

300

300

Ejection capacity

mm

15

25

30

30

30

Max. Stroke of Ejection

mm

165

150

200

200

220

Max. Stroke of ram

mm

400

500

550

550

600

Open height

Max

mm

710

800

950

1000

1110

Min

mm/s

310

300

400

450

510

Down No load

mm/s

300

350

320

350

350

Speed of ram

Pressing

mm/s

21-45

55-150

25-50

25-56

21-47

Return

mm/s

260

350

300

360

360

Speed of cushion piston

Up

mm/s

120

150

150

145

145

Down

mm/s

Down with ram

Down with ram

Down with ram

Down with ram

Down with ram

Motor output

kW

30

45

37

58.5

58.5

Bed Area ( RL x FB )

mm

600 x 700

700 x 700

700 x 880

800 x 990

860 x 1000
